Product reference sheet
Product information for planning, purchasing and the work ahead.
Copeland Hermetic Scroll Compressor R410A, 16,000BTU, 208/230Vac, Single Phase
- Brand
- Copeland
- SKU / Item reference
- Item # 41223579 | Model # ZP16K5E-PFV-830
Supplied specifications
- Color / finish
- Black
Product overview
FEATURES & BENEFITS
• Compressor Type: Scroll• BTU Rating: 16,000• Refrigerant: R410A• Connection Type: Molded Plug (Not Included)• Oil: POE (Polyol Ester)• Voltage: 208/230Vac• Single Phase• Capacitor Rating: 30/370µF• MCC: 14• LRA: 48• RLA: 10• Hertz: 60• Suction Line Size: 3/4"• Suction Line Height: 10.4"• Discharge Line Size: 1/2"• Discharge Line Height: 13.82"
Electrical
Hertz
60
Phase
1
RLA
10
Voltage
208/230
Specification
BTU Rating
16 to 20kBTU
Oil
POE (Polyester)
Suction Line Height
10.3"
Discharge Line Height
14.15"
Discharge Line Size
1/2"
BTU Output
16000
Compressor Type
Scroll
Refrigerant
R-410A
Safety Standards
California Prop 65
Yes
Weights and Dimensions
Operating Weight (lbs)
49.05
Exterior Dimensions (D) (inches)
6.900000
Exterior Dimensions (W) (inches)
8.300000
Exterior Dimensions (H) (inches)
15.300000
Shipping Weight (lbs)
80.000000
Warranty
Country of Origin
United States
