RELIABILT 4-in H Oil-Rubbed Bronze Security Interior Door Hinge
- Brand
- ReliaBilt
- SKU / Item reference
- Item #3635256 | Model #06-2554
- UPC / Barcode
- 945133525546
Supplied specifications
- Dimensions
- Height Measurement
4-in
Minimum Door Thickness (Inches)
1.25
Hinge Thickness (Inches)
0.09
Recommended Door Thickness (Inches)
1.5
Load Capacity per Hinge (lbs.)
60
Width (Inches)
4
Maximum Door Thickness (Inches)
1.75 - Material
- Steel
Product overview
4-In half square half 5/8R security door hinge with oil rubbed bronze finish.
Typically used for doors with a metal jamb and wood door
Half square corner and half 5/8-in radius hinge with oil rubbed bronze finish
Security tab that prevents door from being removed when closed
Removable pin, full mortise
All mounting hardware is included for easy installation
Beautiful finish to coordinate with your existing door hardware
Typically used for doors with a metal jamb and wood door
Half square corner and half 5/8-in radius hinge with oil rubbed bronze finish
Security tab that prevents door from being removed when closed
Removable pin, full mortise
All mounting hardware is included for easy installation
Beautiful finish to coordinate with your existing door hardware
