Copeland Hermetic Scroll Compressor R410A, 54,000BTU, 460Vac, Three Phase
- Brand
- Copeland
- SKU / Item reference
- Item # 41223573 | Model # ZP54K5E-TFD-830
Supplied specifications
- Color / finish
- Black
Product overview
FEATURES & BENEFITS
• Compressor Type: Scroll• BTU Rating: 54,000• Refrigerant: R410A• Connection Type: Molded Plug (Not Included)• Oil: POE (Polyol Ester)• Voltage: 460Vac• Three Phase• Capacitor Rating: Not Required (Compressor is Three Phase)• MCC: 12.1• LRA: 52• RLA: 8.6• Hertz: 60• Suction Line Size: 7/8"• Suction Line Height: 11.5"• Discharge Line Size: 1/2"• Discharge Line Height: 15.34"
Electrical
Hertz
60
Phase
3
RLA
8.6
Voltage
460
Specification
BTU Rating
51 to 55kBTU
Oil
POE (Polyester)
Suction Line Height
11.50"
Discharge Line Height
15.34"
Discharge Line Size
1/2"
BTU Output
54000
Compressor Type
Scroll
Refrigerant
R-410A
Safety Standards
California Prop 65
Yes
Weights and Dimensions
Operating Weight (lbs)
75.95
Exterior Dimensions (D) (inches)
13.100000
Exterior Dimensions (W) (inches)
14.700000
Exterior Dimensions (H) (inches)
19.900000
Shipping Weight (lbs)
106.000000
Warranty
Country of Origin
United States of America
