Home » Eaton 20-Amp 125-volt Tamper Resistant Weather Resistant GFCI Residential Decorator Outlet, White
Eaton

Eaton 20-Amp 125-volt Tamper Resistant Weather Resistant GFCI Residential Decorator Outlet, White

Ships from manufacturer
SKU: Item # 31223432 | Model # TWRGF20W-BX-LW
Special Order $37.00 inc. VAT

Ways to get this item

Shipping
Est. dispatch in 1–7 business days
Pickup
Est. ready in 1–5 business days

Estimates depend on stock, order cutoff, destination and working days. Final options are confirmed at checkout or with our team.

Product at a glance

Full specifications
Model # TWRGF20W-BX-LW
Color / finish
White
Voltage
125-Volt
%3Cp%3EEarn%20[points_amount]%20when%20you%20buy%20this%20item.%3C/p%3E
Keep your supplies organized.

Create a branded label with a QR code to scan and reorder this exact option.
View comparison View comparison Choose up to 4 products to compare.

Product details

Product overview

Eaton's GFCI Duplex Receptacles are designed with the safety of the user in mind and are fully compliant with all the latest NEC code requirements. GFCIs provide state-of-the-art, dependable electrical shock protection, and conduct an automatic self-test periodically to ensure the integrity of GFCI protection. The devices incorporate a safety lock-out feature that protects against mis-wired line-load connections that can cause damage to the GFCI circuitry. In addition to being tested to the highest standards to help ensure safety, GFCIs will deny power and prevent re-setting if the device is no longer able to provide safe, protected power. Tamper resistant (TR) receptacles feature a built-in UL listed safety shutter system that prevents the insertion of foreign objects into the receptacle openings. The safety shutters will only open when a two-bladed plug presses simultaneously against the two shutters. Weather resistant (WR) GFCIs feature corrosion resistant hardware and UV resistant materials designed to withstand the elements.

  • Slimmer design for easy installation, leaving more room for wires in the box

  • Automatically self tests periodically to ensure GFCI protection

  • Child-safety black tamper resistant shutters help prevent improper insertion of foreign objects

  • GFCIs incorporate lock-out functionality to protect against mis‑wired line‑load connections and GFCI circuitry damage

  • Nickel-plated stainless steel strap and screws for added corrosion resistance

  • Wider button wells for easy TEST and RESET

  • Intuitive LED status indicators for trip and end of life states

  • Clean, modern industrial design with reduced top housing markings and neutral text direction on buttons

  • Automatic grounding system eliminates need for bonding jumper in grounded metal enclosure, provides redundant measure of ground continuity where jumper is used

    Technical information

    Specifications

    Brand / manufacturer
    Eaton
    SKU
    Item # 31223432 | Model # TWRGF20W-BX-LW
    UPC / barcode
    032664007682
    Product category
    GFCI
    Item weight
    1.0 lb
    Color / finish
    White
    Style
    GFCI
    Grade
    Residential
    Voltage
    125-Volt
    Amperage
    20-Amp
    Product location
    Aisle: 22 | Bay: 11
    Saber exclusive
    No
    Technical specifications
    AFCI Protection
    No
    Rust Resistant
    No
    Amperage
    20
    Self-Test
    Yes
    Audible Alarm
    No
    Style
    Decorator
    Connection Type
    Back wire (clamp) or side wire
    Surge Protection
    No
    For Use with Mobile Homes
    No
    Tamper Resistant
    Yes
    For Use with RVs
    No
    USB Port
    No
    Function Type
    Receptacle outlet
    USB Type
    N/A
    GFCI Protection
    Yes
    Use Location
    Indoor/Outdoor
    Grade
    Residential
    Voice Controlled
    No
    Grounding Type
    Self-grounding
    Volts
    125-volt
    Hub Required
    No
    Wall Plate Included
    No
    Lockable
    Yes
    Weather Resistant
    Yes
    NEMA Configuration
    5-20R
    Wire Type
    Copper
    Night Light
    No
    Wireless
    No
    Number of Outlets
    2
    Wiring Type
    3-wire grounding

    Product resources

    Guides, documents & data sheets

    Browse the document library → How to measure this project →

    Before you order

    Product questions

    What voltage is listed for this option?
    125-Volt

    Shipping & pickup

    Shipping

    Estimates reflect the selected item and order timing. Dispatch is when your order leaves the supplier; arrival also depends on carrier transit and your destination.

    Read shipping policy →

    Pickup

    Pickup availability depends on the product and location. Check the options above or contact our team with your SKU.

    Call (915) 598-8598 →

    Warranty, returns & product notices

    Manufacturer warranty
    1-year limited
    Return eligibility
    30-Day
    California Proposition 65
    No
